Customise XigmaNas build, adding drivers and Navidrome

⏲ Posted on Thursday 15 October 2026

Let's build XigmaNas from source!

What could go wrong?

I am a total FreeBSD noob and a terrible ~~C/Python~~ programmer. But I love me some XigmaNas. I really like the "firmware" model, it bootstraps itself up into a RAM disk and the original boot files and OS are never accessible, so in theory can't get corrupted. I've been running it at home for years, I forget how many, maybe 10 years? And it is rock solid.

XigmaNAS is an Open Source Storage NAS (Network-Attached Storage) distribution based on FreeBSD.

Navidrome is a self-hosted, open source music server and streamer.

What are you doing!?

Building an OS from source can be a little daunting.

Which release of XigmaNas are you trying to build? Why are you doing this?

Maybe you don't need to do this at all? Maybe bhyve or a vm can do it for you?

For stability reasons I suggest to NOT use the Xigmanas trunk, but the last stable release. Just based on the vibes. And my pain.

Today (Oct 2026) that is 14.3.0.5

But hey, go for it.

You need to get your ducks in a row.

The Xigma release will reference a FreeBSD release, e.g. for XigmaNas-14.3 this is FreeBSD releng/14.3

You need the ports branch to match the FreeBSD branch.

releng - "release engineering branch", a little FreeBSDism.

This guide is to help me bake in the realtek-re-kmod drivers for the RTL8125 chipset, used in my cheap TPLink 2.5Gbe card.

And to add Navidrome as a service.

The XigmaNas releases are not exactly reproducible builds. If you are expert at FreeBSD, ports and make then you will probably have a better time than I did.

The more I learn the more I see that this is not a XigmaNas issue, but more a FreeBSD issue.

The main issue is building the ports. Due to many dependencies, transitive dependencies, missing libraries, changes between versions of FreeBSD we find DEPENDENCY HELL. Ooooo. Go search for "freebsd cython conflict". It seems FreeBSD has been a bit laissez faire in dependency management between, or even within, versions...

Orientation

I am operating on this repository - https://svn.code.sf.net/p/xigmanas/code/branches/14.3.0.5/

In the /build folder we find the main make.sh which delegates pretty much everything to functions.inc.

Within functions.inc I found it helpful to find the menu item in the build I was having trouble with and follow the code from there, usually through a choice.

The /ports directory is important. Here we find all the Makefiles for each port, and also a /distfiles folder that has some "special" dependencies. Notice also the /ports/Makefile here.

The /kernel-config folder holds a modules.files file, which shows the kernel drivers being used.

Branches, tags, ports and kernel

It took many attempts to find this. This is NOT the right branch for the ports, but I'm pretty sure there is no right branch. This branch produced the least errors.

Important - much pain if the branches don't line up

FreeBSD: releng/14.3 (https://git.freebsd.org/src.git)
(Commit: 833d39bd2e38421a14ea489a956261a0fa993fbc)

Xigmanas: 14.3.0.5 (https://svn.code.sf.net/p/xigmanas/code/branches/14.3.0.5/)
(Revision: 10655)

Ports: 14.2-eol (https://cgit.freebsd.org/ports/tree/databases?h=14.2-eol)
(Commit: 4e450f33b9f9cf668688f9c439c58871751e2bbb)

Fix the ports

With 14.2-eol I had three failures, which can be resolved:

php84-APCu

/usr/local/xigmanas/svn/build/ports/php84-APCu/Makefile

Can be fixed by updating the Makefile to be like the one from trunk - remove lang/php84 dependency.

BUILD_DEPENDS=	${NONEXISTENT}:devel/pecl-APCu \
		php84:lang/php84

Replace with: BUILD_DEPENDS= ${NONEXISTENT}:devel/pecl-APCu

samba422

Note: we do this before make.sh is run.

samba422 - cython conflict - removing cython3 fixed it.

I cannot figure out what causes this.

Removing cython3 removes the conflict.

pkg-static delete -f py311-cython3

We will need to run this before we run make.sh

vbox

vbox seems to be hitting swap issues!

The error message suggests to add to Makefile /usr/ports/emulators/virtualbox-ose-72/Makefile in /usr/ports - MAKE_JOBS_UNSAFE=yes which limits make to single thread. :(

We can set in make.conf instead and scope it to the "problem areas". Yes, Claude told me this.

.if ${.CURDIR:M*/devel/llvm19}
MAKE_JOBS_NUMBER=4
.endif

python311

Probably related to cython? Who knows.

The shipped Makefile for the XigmaNas version of python311 expects the /usr/ports/ version of python311 to have been built.

This error turns up while installing ports, so very late in the game.

cd /usr/ports/lang/python311
make stage

This seems very odd, the XIgamNas version seems to just want to install the host python311?

I do not understand what I am looking at.

This line in the Makefile seems... wrong?

DEP_STAGEDIR= ${PORTSDIR}/lang/python311/work/stage

Realtek driver

The realtek card I care about uses chipset RTL8125. The realtek drivers (re) shipped by FreeBSD DO NOT support this at this time. Or in v15 either.

Hence we build the ports/net/realtek-re-kmod port and install.

Create QEMU FreeBSD

https://download.freebsd.org/ftp/releases/amd64/amd64/ISO-IMAGES/14.3/

Use the FreeBSD-14.3-RELEASE-amd64-disc1.iso.

Time has moved on and 14.3 is no longer hosted there (14.4+ as of right now). You may need to shop around.

Make the FreeBSD build VM

Create a FreeBSD 14.3 build machine. I have allocated 16GB RAM and 140GB drive space. You might get away with less RAM. The build takes hours, so give it what you can. I did find I ran out of diskspace at 100GB... so 140GB is good.

#!/bin/bash

# this a build machine, need CPU
# 140GB HDD, 16GB RAM and 8 cores
qemu-img create -f qcow2 freebsd-img.qcow2 140G

# ssh port 22 is forwarded to 2222
qemu-system-x86_64 -cdrom ../FreeBSD-14.3-RELEASE-amd64-disc1.iso -cpu host -enable-kvm -m 16384 -smp 8 -drive file=./freebsd-img.qcow2,format=qcow2 -net nic -net user,hostfwd=tcp::2222-:22

Had to install qemu-system-x86_64 on my host, but all good.

Installing FreeBSD

Pretty much just accept all defaults.

Install with lib32, NOTE: not the lib32-dbg

No point installing ports or src as these are pulled later via git.

Used Auto UFS/GPT and the whole disk. The XigmaNas dev guide suggests two partitions, a 4GB swap and a larger /. I just took the defaults, which was a 4GB swap.

Enter new root password. It rhymes with groot.

Accept all defaults for ipv4 and ipv6.

Set timezone and region.

Do not add any users we will run as root.

And reboot.

Prepare the VM - enable ssh

Enable SSH on the VM:

# run this on the VM
pkg install -y nano git subversion

# uncomment this in /etc/ssh/ssh_config
# PasswordAuthentication yes
nano /etc/ssh/ssh_config

# enable this in /etc/ssh/sshd_config
# PermitRootLogin yes
nano /etc/ssh/sshd_config

service sshd restart

mkdir /usr/local/xigmanas

# used later for sshfs
mkdir ~/xigma

SSH to the VM

Can get the ip address locally via ifconfig and look for the virtbr virtual bridge, this time it's 192.168.122.1.

ssh root@192.168.122.1 -p2222

You may need to remove the old key if this is not your first attempt. Read the error message.

Add ssh-fs fileshare

You can do this later if you want. Assuming this build actually works we want to be able to copy the disk image back to our desktop.

On the VM I made this directory in my (root) home ~/xigma. And you should already have this directory /usr/local/xigmanas in the VM.

sshfs -o port=2222 root@192.168.122.1:/usr/local/xigmanas ~/xigma

The XigmaNas Readme - hmmmm...

Follow the readme at https://sourceforge.net/p/xigmanas/code/HEAD/tree/branches/14.3.0.5/build/README but it's misleading.

It's pretty much correct, just any mention of ports, or pulling the ports has to be taken with a large chunk of salt.

Primarily it does not specify where the ports come from, which leads to much cursing.

We pull the BSD source and ports ourselves.

Prepare the build environment

Update /etc/make.conf

Read the file in the source for the latest.

OPTIONS_UNSET=X11
DEFAULT_VERSIONS+=mysql=8.0
DEFAULT_VERSIONS+=ssl=base
DEFAULT_VERSIONS+=php=8.4

# due to 14.3 being so "old", i mean it's been over a year...
ALLOW_UNSUPPORTED_SYSTEM=yes
# oh my
DISABLE_VULNERABILITIES=yes

# vbox build blows up the swap
.if ${.CURDIR:M*/devel/llvm19}
MAKE_JOBS_NUMBER=4
.endif

Get the "right" ports

Now get the ports up to date with dependancies.

# update the ports tree
rm -rf /usr/ports
git clone --depth 1 --branch 14.2-eol https://git.FreeBSD.org/ports.git /usr/ports

# pull the src - note: releng/14.3 - or do this later via the build menu
# although with --depth 1 this way is faster ~350MB vs ~1.8GB
rm -rf /usr/src
git clone --depth 1 -b releng/14.3 https://git.freebsd.org/src.git /usr/src

# Pull the source for XigmaNas 14.3.0.5
cd /usr/local/xigmanas && svn co https://svn.code.sf.net/p/xigmanas/code/branches/14.3.0.5/ svn

We want all packages built from the same sources to avoid any weird dependancy issues. Ha!

Edit the php84-APCu Makefile

/usr/local/xigmanas/svn/build/ports/php84-APCu/Makefile

Can be fixed by updating the Makefile to be like the one from trunk - remove lang/php84 dependency.

BUILD_DEPENDS=	${NONEXISTENT}:devel/pecl-APCu \
		php84:lang/php84

Replace with: BUILD_DEPENDS= ${NONEXISTENT}:devel/pecl-APCu

Adding the navidrome port

While we still have nano available, and before running the make.sh.

cp -R /usr/ports/multimedia/navidrome/ /usr/local/xigmanas/svn/build/ports/navidrome
echo "OFF" > /usr/local/xigmanas/svn/build/ports/navidrome/pkg-state

Update the /usr/local/xigmanas/svn/build/ports/Makefile and add:

    SUBDIR += navidrome

Update the Navidrome /usr/local/xigmanas/svn/build/ports/navidrome/Makefile

There is some manual intervention required later on - so watch out for that.

Adding the realtek port

We will build the port, but later we will NOT install it. The install goes to the modules folder instead of ports.

cp -R /usr/ports/net/realtek-re-kmod/ /usr/local/xigmanas/svn/build/ports/realtek-re-kmod
echo "OFF" > /usr/local/xigmanas/svn/build/ports/realtek-re-kmod/pkg-state

Update the /usr/local/xigmanas/svn/build/ports/Makefile and add:

    SUBDIR += realtek-re-kmod

Making the memory disk bigger

After including Navidrome the image exceeds the size of the memory disk. We need to extend that for the creation of the LiveCD ISO and for the actual memory disk when xigmanas is running.

The two files (rc and functions.inc) MUST agree on the memory disk size - in this case 1600MB

Edit the /usr/local/xigmanas/svn/etc/rc file:

Replace:

# Fixed values requested by build/make.sh
MDLOCALSIZE=1332m
SWAPSIZE=512m

With:

# Fixed values requested by build/make.sh
MDLOCALSIZE=1800m
SWAPSIZE=512m

Edit the /usr/local/xigmanas/svn/build/functions.inc file.

Note the XIGMANAS_MDLOCAL_SIZE variable.

Replace:

#	Size in MB of the MFS Root filesystem that will include all FreeBSD binary
#	and XigmaNAS® WebGUI/Scripts. Keep this file very small! This file is unzipped
#	to a RAM disk at XigmaNAS® startup.
#	The image must fit on 2GB CF/USB.
#	Actual size of MDLOCAL is defined in /etc/rc line 38.
XIGMANAS_MFSROOT_SIZE=132
XIGMANAS_MDLOCAL_SIZE=1192
XIGMANAS_MDLOCAL_MINI_SIZE=36
#	Now image size is less than 500MB (up to 476MiB - alignment)
XIGMANAS_IMG_SIZE=460
if [ "amd64" = ${XIGMANAS_ARCH} ]; then
	XIGMANAS_MFSROOT_SIZE=144
	XIGMANAS_MDLOCAL_SIZE=1332
	XIGMANAS_MDLOCAL_MINI_SIZE=52
	XIGMANAS_IMG_SIZE=500
fi

With:

#       Size in MB of the MFS Root filesystem that will include all FreeBSD binary
#       and XigmaNAS® WebGUI/Scripts. Keep this file very small! This file is unzipped
#       to a RAM disk at XigmaNAS® startup.
#       The image must fit on 2GB CF/USB.
#       Actual size of MDLOCAL is defined in /etc/rc line 38.
XIGMANAS_MFSROOT_SIZE=132
XIGMANAS_MDLOCAL_SIZE=1800
XIGMANAS_MDLOCAL_MINI_SIZE=36
#       Now image size is less than 500MB (up to 476MiB - alignment)
XIGMANAS_IMG_SIZE=460
if [ "amd64" = ${XIGMANAS_ARCH} ]; then
        XIGMANAS_MFSROOT_SIZE=144
        XIGMANAS_MDLOCAL_SIZE=1800
        XIGMANAS_MDLOCAL_MINI_SIZE=52
        XIGMANAS_IMG_SIZE=500
fi

Build some prerequisites

# removes the pkg we installed - git, subversion, nano and a few other things
pkg delete -y -f \*
cd /usr/ports/shells/bash && make BATCH=yes install clean

cd /usr/ports/ports-mgmt/portupgrade && make BATCH=yes install clean

cd /usr/ports/sysutils/cdrtools && make BATCH=yes install clean

cd /usr/ports/devel/subversion && make BATCH=yes install clean

cd /usr/ports/devel/git && make BATCH=yes install clean

Build XigmaNas - run the make file

Remove the cython problem and run make.sh.

pkg-static delete -y -f py311-cython3

/usr/local/xigmanas/svn/build/make.sh

And it begins...

-------------------------------------------------------------
		Build Environment XigmaNAS®
-------------------------------------------------------------
Choice Menu:

1) - Update XIGMANAS_SVNDIR to latest XigmaNAS Source Files.
2) - Enter Compile Menu.

-------------------------------------------------------------
Generate Images:
10) - Create 'Embedded.img.xz' File.         (Firmware Update)
11) - Create 'LiveUSB.img.gz MBR' File.   (Rawrite to USB Key)
12) - Create 'LiveUSB.img.gz GPT' File.   (Rawrite to USB Key)
13) - Create 'LiveCD' (ISO) File.
14) - Create 'LiveCD-Tin' (ISO) Without 'Embedded' File.
15) - Create 'Full' (TGZ) Update File.
16) - Create All Release images at once.
-------------------------------------------------------------
17) - Create translations xigmanas.pot file from Source files.

*)  - Exit.

1 - We can skip. it just pulls the "https://svn.code.sf.net/p/xigmanas/code/trunk" again. Useful if you maintained this build machine.

2 - We MUST run this. Must.

-------------------------------------------------------------
		Build Environment XigmaNAS®
-------------------------------------------------------------
Compile Menu:

1) - Update FreeBSD Source Tree and Ports Collections.
2) - Create Filesystem Structure.
3) - Build/Install the Kernel.
4) - Build World.
5) - Import base-ports to their locations.
6) - Build Ports.
7) - Build Bootloader.
8) - Add Necessary Libraries.
9) - Modify File Permissions.
-------------------------------------------------------------

*) - Exit Compile Menu.

2.1 Update FreeBSD Source Tree and Ports Collections.

1. Pull FreeBSD src source tree - this is a clone, deletes the /usr/src directory and clones
1. Update FreeBSD src source tree - is a pull
1. Fetch and install binary updates - updates this vm install
1. Update ports collection - does a git pull on the /usr/ports
1. Upgrade pkg on host - like an apt update/upgrade on this vm

If you already pulled the FreeBSD source then you can skip this whole menu item.

If not - Run 1. That is all.

2.2 - Create Filesystem Structure.

Yes - run this. Sets things up in /usr/local/xigmanas/rootfs

2.3 - Build/Install the Kernel.

Apply kernel patches
Build kernel
Install kernel + modules

Run all of these. You can select all three at once.

The install kernel + modules step is the bit we need to copy later to install the realtek driver.

2.4 - Build World.

Yes - run this. Copies a bunch files around.

2.5 - Import base-ports to their locations.

Yes - run this. Updates some of the /usr/ports/distfiles with build specific things.

2.6 - Build Ports.

1. Build ports
1. Build ports (dev only, no preselection)
1. Re-build ports (dev only)
1. Install ports

Run 1 & 4.

This takes ages. Like, 8 hours. And sometimes has a dialog you have to hit enter on. Although that might have been Navidrome. Hopefully the make.conf settings have shut it all up.

You should see navidrome in the list. And realtek-re-kmod too. Cool.

Do NOT build navidrome yet. Build everything else.

Insert SpongeBob Time Card meme here.

Exit back to the shell and fix python311

# to fix problem with installing ports
cd /usr/ports/lang/python311 && make BATCH=yes stage

Run make.sh again and return to this menu.

When we run 4 deselect the realtek-re-mod and the navidrome port.

Install everything else.

Rerunning the "Install" step is very brittle. You MUST rebuild or make clean the port before trying to reinstall.

At this point we can stop and exit the make.sh

We need to get the realtek module in place.

Adding the realtek-re-kmod

We should have built the driver now. We can install it into the image we are creating.

Check the path below is correct, the if_re.ko file was in a folder rtl_bsd_drv-ea4ed1e whcih apparently is the git hash, so the folder might be different.

install -v -o root -g wheel -m 555 \
    /usr/local/xigmanas/svn/build/ports/realtek-re-kmod/work/*/if_re.ko \
    /usr/local/xigmanas/rootfs/boot/modules

Adding the navidrome port

cd /usr/local/xigmanas/svn/build/ports/navidrome

make BATCH=yes stage

# manual installation into the xigmanas rootfs
R=/usr/local/xigmanas/rootfs/usr/local
mkdir -p $R/bin $R/etc/rc.d $R/etc/navidrome
install -m 555 work/stage/usr/local/bin/navidrome $R/bin/
install -m 555 work/navidrome $R/etc/rc.d/navidrome
install -m 644 work/stage/usr/local/etc/navidrome/config.toml.sample $R/etc/navidrome/

And now - back to /usr/local/xigmanas/svn/build/make.sh.

Select 2 and then 7 to continue below.

2.7 - Build Bootloader.

Yes - run this.

2.8 - Add Necessary Libraries.

Just run the first option - "Add required libraries". Becuase they are required. Duh.

2.9 - Modify File Permissions.

Just run it.

Carry on building

I create the following images, for testing and the real installation:

12) - Create 'LiveUSB.img.gz GPT' File.   (Rawrite to USB Key)
13) - Create 'LiveCD' (ISO) File.

Oh, we done!

Write the image

OK... how do I get it off the VM?

Earlier we made this directory in the home (root) folder on the VM ~/xigma

Mount this via sshfs.

sshfs -o port=2222 root@192.168.122.1:/usr/local/xigmanas ~/xigma

We should find

XigmaNAS-x64-LiveCD-14.3.0.5.10655.iso
XigmaNAS-x64-LiveUSB-GPT-14.3.0.5.10655.img.gz

We can mount the LiveCD ISO on another QEMU VM and test.

qemu-img create -f qcow2 xigmatest.qcow2 40G

# start with live cd
qemu-system-x86_64 -cpu host -enable-kvm -m 8192 -smp 4 \
  -cdrom ./XigmaNAS-x64-LiveCD-14.3.0.5.10655.iso \
  -drive file=./xigmatest.qcow2,format=qcow2 \
  -net nic -net user,hostfwd=tcp::2224-:22,hostfwd=tcp::8080-:80

# after installing, eject the cd, expose navidrome port
qemu-system-x86_64 -cpu host -enable-kvm -m 8192 -smp 4 \
  -drive file=./xigmatest.qcow2,format=qcow2 \
  -net nic -net user,hostfwd=tcp::2224-:22,hostfwd=tcp::8080-:80,hostfwd=tcp::4533-:4533

You can install Xigmanas to this VM, configure the NIC's and DHCP. After install, shutdown the VM and restart without the CD.

You should get an IP like 10.0.2.15. I can access the web gui via http://localhost:8080, enable ssh. And all good.

Test realtek-re-kmod as best we can

Does the module exist?

ls -l /boot/modules/if_re.ko

Can we load the module - should get no errors.

kldload /boot/modules/if_re.ko

This VM does not have the hardware, so the rest of the config can happen later.

Test Navidrome

Copy the sample config:

cp /usr/local/etc/navidrome/config.toml.sample /usr/local/etc/navidrome/config.toml
service navidrome onestart

And hit it on http://localhost:4533.

Great. More config is needed, but that can happen on the real thing. Or practice here.

Install Xigmanas on your NAS

Backup your config.

Install xigmanas.

Restore config.

Configure realtek-re-kmod driver to load.

Via the web gui:

Navigate to System>Advanced>loader.conf

Add two entries:

if_re_load="YES"
if_re_name="/boot/modules/if_re.ko"

These end up in the config.xml file as:

<loaderconf>
	...
	<param>
		<uuid>deadbeef-dead-c0de-face-8badcafef00d</uuid>
		<enable type="bool">1</enable>
		<name>if_re_load</name>
		<value>YES</value>
		<comment/>
	</param>
	<param>
		<uuid>deadbeef-dead-c0de-face-8badcafef00d</uuid>
		<enable type="bool">1</enable>
		<name>if_re_name</name>
		<value>/boot/modules/if_re.ko</value>
		<comment/>
	</param>

Navigate to System>Advanced>Command Scripts

In theory we should not need to do the following. In practice we do. I do not know why.

Add new preinit script with the command kldload if_re

Reboot.

Should now be able to configure the NIC to the realtek one.

Configure Navidrome

Read the navidrome freebsd config setup guide.

We need somewhere to store Navidrome's metadata. I made a new partition on my boot drive, but it could just be a folder on some disk.

I made /mnt/navidrome-data and mounted via the web gui so it is persistant.

We need a bunch of rc.conf. Navidrome will respect these settings over the config.toml.

	<name>navidrome_enable</name>
	<value>YES</value>

	<name>navidrome_datafolder</name>
	<value>/mnt/navidrome-data</value>

	<name>navidrome_config</name>
	<value>/mnt/navidrome-data/config.toml</value>

Edit the config.toml

Comment the ipaddress out so it responds on all nics and uncomment the port.

Via ssh to Xigmanas set:

chown -R www:www /mnt/navidrome-data

And reboot.

We can now hit the navidrome gui at http://192.168.1.xxx:4533

Put it all together

Script I run once SSH and SSHFS is working on the VM. I copy it into a build.sh and off it goes.

The below is slightly different to above - pulls navidrome from the 2026Q2 branch as I wanted the multi library feature. It's just pulling that branch and copying the port folder as before, just a different version. This version's dependencies still seem satisfied by the 14.2-eol branch, so things work.

You still have to bail out while building the ports, but this is mostly non-interactive.

Just let it cook.

#!/bin/sh

# this should have been done when setting up ssh
# mkdir /usr/local/xigmanas
# used for sshfs
# mkdir ~/xigma

pkg install -y git subversion

cat > /etc/make.conf << 'EOF'
OPTIONS_UNSET=X11
DEFAULT_VERSIONS+=mysql=8.0
DEFAULT_VERSIONS+=ssl=base
DEFAULT_VERSIONS+=php=8.4

# due to 14.3 being so "old", i mean it's been over a year...
ALLOW_UNSUPPORTED_SYSTEM=yes
# oh my
DISABLE_VULNERABILITIES=yes

# vbox build blows up the swap
.if ${.CURDIR:M*/devel/llvm19}
MAKE_JOBS_NUMBER=4
.endif
EOF

# update the ports tree
rm -rf /usr/ports
git clone --depth 1 --branch 14.2-eol https://git.FreeBSD.org/ports.git /usr/ports

# pull the src - note: releng/14.3 - or do this later via the build menu
# although with --depth 1 this way is faster ~350MB vs ~1.8GB
rm -rf /usr/src
git clone --depth 1 -b releng/14.3 https://git.freebsd.org/src.git /usr/src

# Pull the source for XigmaNas 14.3.0.5
cd /usr/local/xigmanas && svn co https://svn.code.sf.net/p/xigmanas/code/branches/14.3.0.5/ svn

# removes the pkg we installed - git, subversion, nano and a few other things
pkg delete -y -f \*
cd /usr/ports/shells/bash && make BATCH=yes install clean

cd /usr/ports/ports-mgmt/portupgrade && make BATCH=yes install clean

cd /usr/ports/sysutils/cdrtools && make BATCH=yes install clean

cd /usr/ports/devel/subversion && make BATCH=yes install clean

cd /usr/ports/devel/git && make BATCH=yes install clean

# tweak php84-APCu to remove lang dependency
sed -i '' -e '/php84:lang\/php84/d' -e '/pecl-APCu/s/ *\\$//' /usr/local/xigmanas/svn/build/ports/php84-APCu/Makefile

# copy in  realtek-re-kmod, navidrome
cp -R /usr/ports/net/realtek-re-kmod/ /usr/local/xigmanas/svn/build/ports/realtek-re-kmod
echo "ON" > /usr/local/xigmanas/svn/build/ports/realtek-re-kmod/pkg-state

# pull the version of navidrome we want v60.x
# this is the last easily compatiable version. next branch needs go126, which is
# not on 14.2-eol
git clone --depth 1 --branch 2026Q2 https://git.FreeBSD.org/ports.git ~/ports

cp -R ~/ports/multimedia/navidrome/ /usr/local/xigmanas/svn/build/ports/navidrome
echo "OFF" > /usr/local/xigmanas/svn/build/ports/navidrome/pkg-state

sed -i '' '/SUBDIR += nano/a\
\    SUBDIR += realtek-re-kmod\
\    SUBDIR += navidrome
' /usr/local/xigmanas/svn/build/ports/Makefile

# fixes issue with samba422 build
pkg-static delete -y -f py311-cython3

# fix up navidrome
f=/usr/local/xigmanas/svn/build/ports/navidrome/Makefile

# BATCH=yes at the top
sed -i '' '1i\
BATCH=yes\

' "$f"

# force to go125 exactly
sed -i '' 's/go:1\.25+,modules/go:1.25,modules/' "$f"

# post-stage target after post-install
printf '\n# add this after the post-install: target\npost-stage:\n\t@${MKDIR} ${XIGMANAS_ROOTFS}${PREFIX}/bin ${XIGMANAS_ROOTFS}${PREFIX}/etc/rc.d ${XIGMANAS_ROOTFS}${PREFIX}/etc/navidrome\n\t@${INSTALL_PROGRAM} -v ${STAGEDIR}${PREFIX}/bin/navidrome ${XIGMANAS_ROOTFS}${PREFIX}/bin\n\t@${INSTALL_SCRIPT} -v ${STAGEDIR}${PREFIX}/etc/rc.d/navidrome ${XIGMANAS_ROOTFS}${PREFIX}/etc/rc.d\n\t@${INSTALL_DATA} -v ${STAGEDIR}${PREFIX}/etc/navidrome/config.toml.sample ${XIGMANAS_ROOTFS}${PREFIX}/etc/navidrome\n' > /tmp/post-stage.txt
sed -i '' '/ETCDIR}\/config.toml.sample$/r /tmp/post-stage.txt' "$f"

# edit the memory disk - bump the size from 1392 to 1600, about 1.5GB of ram
sed -i '' -e 's/^MDLOCALSIZE=1332m$/MDLOCALSIZE=1800m/' -e '/^SWAPSIZE=512m$/G' /usr/local/xigmanas/svn/etc/rc
sed -i '' -E 's/XIGMANAS_MDLOCAL_SIZE=(1192|1332)/XIGMANAS_MDLOCAL_SIZE=1800/' /usr/local/xigmanas/svn/build/functions.inc

/usr/local/xigmanas/svn/build/make.sh


# once we get up to the ports build
# we can build realtek-re-kmod
# DO NOT build navidrome
# complete the build phase (takes about 8 hours)
# exit out and run

# to fix problem with installing ports
# cd /usr/ports/lang/python311 && make BATCH=yes stage

# then install all ports except navidrome and realtek-re-kmod
# then via the build menu build navidrome
# then exit out again

# install -v -o root -g wheel -m 555 \
#     /usr/local/xigmanas/svn/build/ports/realtek-re-kmod/work/*/if_re.ko \
#     /usr/local/xigmanas/rootfs/boot/modules

# cd /usr/local/xigmanas/svn/build/ports/navidrome
#
# make BATCH=yes stage
#
# R=/usr/local/xigmanas/rootfs/usr/local
# mkdir -p $R/bin $R/etc/rc.d $R/etc/navidrome
# install -m 555 work/stage/usr/local/bin/navidrome $R/bin/
# install -m 555 work/navidrome $R/etc/rc.d/navidrome
# install -m 644 work/stage/usr/local/etc/navidrome/config.toml.sample $R/etc/navidrome/

# fix samba which is broken now too for some unknown reason

# mkdir -p /usr/local/xigmanas/rootfs/usr/local/libdata/ldconfig
# echo /usr/local/lib/samba4 > /usr/local/xigmanas/rootfs/usr/local/libdata/ldconfig/samba4
# cat /usr/local/xigmanas/rootfs/usr/local/libdata/ldconfig/samba4

# rerun make and carry on from "step 7" of the compile menu

Customise XigmaNas build, adding drivers and Navidrome

Let's build XigmaNas from source!

What are you doing!?

Orientation

Branches, tags, ports and kernel

Fix the ports

Realtek driver

Create QEMU FreeBSD

Make the FreeBSD build VM

Installing FreeBSD

Prepare the VM - enable ssh

SSH to the VM

Add ssh-fs fileshare

The XigmaNas Readme - hmmmm...

Prepare the build environment

Get the "right" ports

Edit the php84-APCu Makefile

Adding the navidrome port

Adding the realtek port

Making the memory disk bigger

Build some prerequisites

Build XigmaNas - run the make file

2 - Compile Menu

Adding the realtek-re-kmod

Adding the navidrome port

Carry on building

Write the image

Install Xigmanas on your NAS

Configure realtek-re-kmod driver to load.

Configure Navidrome

Put it all together
